AccurioLabel 230

Share

The benefits of digital label printing are clear: fast turnaround, no plate-making, high profitability, skill-less operation, just to name a few...

Caracteristici

Caracteristici cheie ale imprimantei AccurioLabel 230

SIMPLITATE ÎN UTILIZARE
- Maintenance tasks on the AccurioLabel 230 are simple and can be performed in a very short amount of time.
- Tasks that are time-consuming on analogue machines, such as colour adjustments, are performed with ease on this digital press
COMPATIBILITATE RIDICATĂ CU MEDIILE DE PRINTARE
- No pre-coating of media requiered
- No special media is requiered
VITEZĂ RIDICATĂ DE IMPRIMARE
- Printing Speed
- With AccurioLabel 230 you can print with max. speed 23.4 m/min
- Most tack paper & films [PP, PET.YUPO] can be printed with max. speed [120 - 160μm thickness]
- Warm Up Time
- No waiting between running jobs
- Minimize paper waste and therefore also costs
- Easy Alignment of Paper Web
- AccurioLabel 230 winders has web guide on both rewinder and rewinder for optimal and accurate feeding of the media

Print job variety
- Overprinting
- With Overprinting Kit, AccurioLabel 230 has the ability to over print on pre-printed media
- Flexo Printing Unit
- This optional module can be retrofitted to the AccurioLabel press in order to pre-print white or any other color for the inline overprinting process
- Two Different Paper Width
- AccurioLabel 230 is possible to change two types of paper width between 250 to 330 mm.
- JDF/JMF
- AccurioLabel 230 is JDF/JMF compatible
Outstanding quality
- Offset Like Resolution
- High resolution of 1,200 dpi x 8 bit produces a high-precision finish
- Feeding Speed Detection
- AccurioLabel 230 equipped with speed detector that detected media feeding speed that helps for more accurate print registration
- Web Cleaning System
- The Web Cleaning System helps to remove any dust or small particles that can affect print quality
- Colour consistency
- Image density control technology
- Advanced colour management tools

SYSTEM SPECIFICATIONS
Technology	Dry Toner Electrophotography
Resolution	1,200 x 1,200 dpi x 8 bit 1,200 x 3,600 dpi equivalent
Paper widths	250 mm to 330 mm
Max. printing image size	1,195 x 320 mm
Max. Printed image width	320 mm
Grammage / substrate thickness	81 to 256 g/m²
Possible substrates	Paper, YUPO, PP, PET
Unit weight	947 kg
Feeding speed (printing speed)	23.4 m/min., 18.9 m/min., 13.5 m/min., 9.45 m/min. Speed depends on the paper type (standard speed: 23.4 m/min)
Unit dimensions (W x D x H)	3,869 x 1,141 x 1,478 mm
Unit weight	942 kg
Web control	Integrated web guide system (BST) on unwinder and rewinder
Converting	Capability to connect selected fi nishing devices

CONTROLLER
Internal Konica Minolta controller	IC-605B

OPTIONS
Overprinting Kit
Web Cleaning System
Air Compressor (if no air supply available on site)
Length-slitting Crush Cutter
